TECHNICAL
|
|
|
Operating System
|
Microsoft Windows Embedded Handheld 6.5
|
|
Processor
|
ARM 9 processor
|
|
Memory
|
128MB RAM / 128MB NAND Flash
|
|
Expansion
|
User-accessible microSD card slot
|
|
Power
|
2880mAh hot-swappable Li-ion battery
|
|
PHYSICAL
|
|
|
Dimensions
|
5.8” H x 2.9” W x 1.0” L /148mm H x 73mm W x 25.4mm L
|
|
Weight
|
13oz / 370g including battery
|
| Keypad |
Numeric |
|
Display
|
3.2 inch QVGA with LED backlight
|
|
Touch Panel
|
Resistive touch screen
|
|
ENVIRONMENTAL
|
|
|
Operating Temperature
|
-4º to 122º F / -20º to 50º C
|
|
Storage Temperature
|
-22º to 158º F / -30º to 70º C
|
|
Humidity
|
5% to 90% RH (no condensation)
|
|
Drop
|
4ft / 1.2m drop to concrete on four sides
|
|
Water & Dust
|
IP64
|
|
Tumble
|
250 3.2' tumbles (250 drops)
|
|
Electro Static Discharge (ESD)
|
+/- 15kVdc air; +/- 8kVdc contact
|
|
Sterilization
|
75.9% to 81.4% concentration alcohol rub
|
|
INTERFACE FEATURES
|
|
|
Audio
|
Speaker and Microphone
|
|
Alerts
|
Vibration; LED indicators; audio beep
|
|
Communication Port
|
Industrial connector
|
| LED Indicators |
Tri-color |
|
Scan Triggers
|
| Left, right, center buttons |
|
DATA CAPTURE
|
|
|
Imager
|
Zebra SE4500 1D/2D CMOS or Motorola SE655 Linear 1D Imager
|
| Laser |
Motorola SE955 |
| RFID |
Reads ISO18000-63, EPC Global Class 1 Gen 2 RFID tags
|
|
WIRELESS COMMUNICATION
|
|
|
WLAN
|
802.11b/g/n
|
|
Security
|
WEP (40 or 128 bit); TKIP; AES; WPA2-PSK; WPA-PSK; WPA2 (EAP-TLS, EAP-PEAP)
|
|
WPAN
|
Bluetooth v2.1 with EDR
|
|
MOBILE APPURTENANCES
|
|
|
Compass
|
API-addressable compass for applications
|
|
ACCESSORIES
|
Single-slot USB/Serial cradle kit
|
| |
Nylon Holster |
SAFETY/REGULATORY
|
|
| Safety |
EN60950-1:2006/A2:2013; EN60601-1-2:2014 |
| EMI |
FCC Part 15 Subpart B:2013; EN55022:2010+AC:2011; EN55024:2010 |
| RF |
FCC Part 15 Subpart C and Subpart B:2013; EN300 328 v1.8.1 (2012-06), EN300 328 v1.9.0; EN301 489-1 v1.9.2 (2012-10-23); EN301 489-17 v2.2.1 (2012-10-23) |
