TECHNICAL
|
|
|
Operating System
|
Android 13 with Google Mobile Services (GMS) or AOSP; Upgradable to 15
|
|
Processor
|
2.4GHz Qualcomm Snapdragon octa-core |
|
Memory
|
4GB/64GB
|
| Expansion |
User-accessible microSD card slot with SDXC support (up to 512GB)
|
|
Power
|
4500mAh rechargeable and removable Li-ion battery
|
|
PHYSICAL
|
|
|
Dimensions
|
6” L x 3” W x .7” D / 152mm L x 76mm W x 18mm D
|
|
Weight
|
9.8oz / 280g including battery |
|
Display
|
5 inch HD (720x1280)
|
|
Touch Panel
|
Multi-touch capacitive touch screen
|
|
ENVIRONMENTAL
|
|
|
Operating Temperature
|
-4º to 140º F / -20º to 60º
|
|
Storage Temperature
|
-40º to 158º F / -40º to 70º C
|
|
Humidity
|
Non-condensing, 95%
|
|
Drop
|
Multiple 5ft / 1.5m drops to concrete on all sides across a wide temperature range |
|
Water & Dust
|
IP65
|
|
Electro Static Discharge (ESD)
|
+/- 15kV air; +/- 8kV contact
|
|
INTERFACE FEATURES
|
|
|
Audio
|
3.5mm headset jack; speaker; microphone
|
|
Alerts
|
Vibration; LED indicators
|
|
Connectors
|
USB 2.0 with Type-C interface
|
|
LED Indicators
|
Dual-color
|
| Motion Sensor |
Accelerometer; Light Sensor; Proximity Sensor
|
| External Buttons |
Side Scan Triggers; Volume Up/Down; Power Button; Function Key |
|
DATA CAPTURE
|
|
|
Imager
|
Honeywell N5703 1D/2D imager; Multi Barcode Scanning
|
| Camera |
13MP color rear-facing with user-controllable LED flash and 5MP front-facing camera
|
| RFID/NFC |
Reads NFC Forum Tag 1 to 5, ISO14443
Type A, ISO14443 Type B, ISO15693, Ml FARE® 1k/4k/Plus/Ultralight/ DESFire, Sony Felica on the 13.56 MHz range
|
|
WIRELESS
COMMUNICATION
|
|
|
WWAN (optional)
|
TD-LTE:B34/B38/B39/B40/B41
FDD-LTE: Bl/2/3/4/5/7 /8/12/13/17 /19/20/B25/ B26/B28A/B28B/B66
WCDMA: B1/B2/B4/B5/B8
TD-SCOMA: B34/39
GSM/EDGE/GPRS: 850/900/1800/1900 CDMA 2000 EVDO/CDMA 1x (800Mhz)
|
|
WLAN
|
802.11a/b/g/n/ac/d/e/h/i/k/r/v/w;
2.4GHz/5GHz Dual-Band
|
| Security |
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA3 Personal (SAE); WPNWPA2 Enterprise (TKIP and AES); WPA3 Enterprise 192-bit mode (GCMP-256) - EAP-TLS; Enhanced Open (OWE)
|
| WPAN |
Bluetooth v5.1 + BR/EDR + BLE
|
| GPS |
GPS (U); A-GPS; BeiDou; GLONASS; Galileo
|
|
ACCESSORIES (sold separately)
|
Single-Slot USB / Charging Cradle Kit; Four-Slot Charging Cradle; Four-Slot Battery Charger; Charging Adapter; Powered Trigger Handle; TSL ePopLoq
|
|
SAFETY/REGULATORY
|
|
|
|
IEC 60950; EMC; RF; SAR; LED; Laser; FCC; IC; CE; RoHS; WEEE
|
