TECHNICAL
|
|
|
Operating System
|
Android 8 (Oreo) with system compatibility up to Android 9 (Pie) *Android Enterprise Recommended (AER)
|
|
Processor
|
1.8 GHz Qualcomm Snapdragon™ 450 octa-core |
|
Memory
|
3GB/32GB
|
| Expansion |
User-accessible microSD card slot with SD, SDHC and SDXC support; 2 Micro SAM slots; Dual-SIM slot |
|
Power
|
2900mAh 3.63v rechargeable Li-ion battery (5800mAh optional)
|
|
PHYSICAL
|
|
|
Dimensions
|
6.2” L x 3.0” W x .7” D / 157.6mm L x 78mm W x 18.8mm D
|
|
Weight
|
9.0oz / 256g including battery |
|
Display
|
5.0” (1080x1920) FHD with Corning® Gorilla® Glass 3; exceptionally bright, outdoor viewable; anti-raindrop; 500 nits |
|
Touch Panel
|
Multi-touch capacitive touch screen
|
|
ENVIRONMENTAL
|
|
|
Operating Temperature
|
-4º to 140º F / -20º to 60º C
|
|
Storage Temperature
|
-13º to 158º F / -25º to 70º C
|
|
Humidity
|
Non-condensing, 95%
|
|
Drop
|
Multiple 6ft / 1.8m drops to concrete at operating temperature per MIL-STD-810G; Multiple 5ft / 1.5m drops to concrete across a wide temperature range per MIL-STD-810G |
|
Water & Dust
|
IP67
|
|
Electro Static Discharge (ESD)
|
+/- 15kV air; +/- 8kV contact
|
|
INTERFACE FEATURES
|
|
|
Audio
|
3.5mm headset jack; 2 speakers; 2 noise-cancelling microphones; Push-to-Talk support
|
|
Alerts
|
Vibration; LED indicators
|
|
Connectors
|
High-Speed USB 2.0
|
|
LED Indicators
|
Dual-color
|
| Motion Sensor |
Gyroscope; Accelerometer; Light Sensor; Proximity Sensor; Digital Compass |
| External Buttons |
9 hard keys; 2 scanner buttons |
|
DATA CAPTURE
|
|
|
Imager
|
Honeywell N3603 1D/2D imager |
| Camera |
13MP color rear-facing autofocus camera with user-controllable LED flash and 5MP front-facing camera |
| RFID/NFC |
Reads ISO14443 Type A; ISO14443 Type B; ISO 15693; MIFARE Classic 1K/4K;
MIFARE UltraLight; MIFARE 1k/4k/Plus; MIFARE DESFire; Sony FeliCA in the 13.56 MHz range |
|
WIRELESS
COMMUNICATION
|
|
|
WWAN
|
EDGE/GPRS/GSM: 900/1800/850/1900
WCDMA: B1/2/4/5/6/8/19
LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/19/20/28
LTE TDD: B38/B39/B40/41
2xCA support: B1+B5/B7/B8/B19; B3+B5//B8/B19; B2+B5/B17; B4+B7/17; B5+B7; Cat6. 300M DL/ 50M UL |
|
WLAN
|
802.11a/b/g/n/ac/d/h/i/k/r/v
|
| Security |
IEEE 802.11n; WEP; WPA/WPA2 Personal (TKIP. AES); WPA/WPA2 Enterprise (TKIP, AES); PEAP(MSCHAPv2, GTC): TLS; TTLS (PAP, MSCHAP, MSCHAPv2, GTC); PWD; SIM; AKA; AKA’, LEAP |
|
WPAN
|
Bluetooth Class I 5.0 (BLE)
|
| GPS |
Qualcomm GPS supports GLONASS, Galileo and Beidou |
|
ACCESSORIES
|
Single-Slot Cradle Kit (USB; Charging)
|
|
Single-Slot Ethernet Cradle Kit |
|
Dual-Slot Charging Cradle Kit |
| |
Four-Slot Battery Charging Kit |
| |
Charging Adapter |
| |
Extended Battery Kit |
| |
Handstrap |
| |
Trigger Handle |
|
SAFETY/REGULATORY
|
|
|
Safety
|
IEC 60950; EMC; RF; SAR; LED; Laser |
|
Radio
|
FCC; IC; GCF; PTCRB; CE; CB; CU; FAC; GEC; KC; RCM |
|
Environment
|
RoHS III and WEEE compliant
|
